Features
- Weighing slip printer
- Large battery for long battery life
- OLED display for easy setup
- Print anytime, anywhere
- Anti-collision design for drop resistance
- Compact size for portability
- Print Method: Direct Thermal
- Resolution: 203 DPI
- Printing Width: 104mm
- Interface: USB+Bluetooth / USB+WIFI
- Print Speed: 101mm (4") / s
Memory
- RAM: 8M
- FLASH: 16M
Built-in Fonts
- Common single-byte fonts: FONT 0 to FONT 8
- Simplified Chinese (GB18030): 16×16, 20×20
- Traditional Chinese (BIG5): 24×24
- Korean (full text)
- Windows fonts (*.ttf) can be downloaded via software
Barcode Character Graphics
-
1D Barcode :Code 39, Code 93, Code 128UCC,
Code 128 subsets A, B, C, Codabar,
Interleaved 2 of 5, EAN-8, EAN-13,
EAN-128, UPC-A, UPC-E,
EAN and UPC 2(5) digits add-on - 2D Barcode: PDF-417, DataMatrix, QR code
- Rotation: 0°, 90°, 180°, 270°
- Graphics: Printing of monochrome PCX, BMP and other image files
Sensors
- Gap sensor
- Cover opening sensor
- Black mark sensor
Power Supply
- Battery: 7.4V rechargeable Li-ion battery, 3000mAh
- Input: AC 100V–240V 50/60Hz
- Output: DC 5V/1A
Paper
- Paper Type: Thermal Receipt Paper
- Paper Width: 30mm ~ 110mm
- Paper Thickness: 0.06 ~ 0.2mm
- Roll Diameter: Max. Ø56 mm
- Paper Load: Easy paper loading
- Paper Cut: Manual tear
Physical Characteristics
- Working Condition: -20°C ~ 52°C, 10% ~ 85% RH, no-condensing
- Storage Condition: -20°C ~ 60°C, 5% ~ 90% RH, no-condensing
- Dimensions: 155(D) × 132(W) × 71(H) mm
- Weight: Net 0.47kg / Gross 0.76kg
Reliability
- Printing head: 50km
Accessories
- USB data cable
- Charging head
- Instruction manual
- Battery
Packing
- Individual box: 210 × 136 × 76 mm (1 unit/carton)
- Master carton: 460 × 290 × 420 mm (20 units/carton)
OS / Compatibility
- Emulation: TSPL, ZPL, CPCL, ESC/POS (Default AUTO)
- Driver: Windows / Mac / Linux
- SDK: Android / iOS / Windows
